Bicycle Reflector Reflex Electroform Mould Core Inserts





Reflex reflector electroform core insert should pay attention to the following:

1. Some Bicycle reflector reflex mold electrocasting parts also require electricians. The electricity should not be installed into the mold core during work. We have to think clearly (this is very important) and pay special attention when taking the reference number of electric discharge machining. The fitter is required to put the corresponding excess. Tell the electrician the amount.
2. The surface finish of reflector reflex bicycle moldelectroforming is extremely high. The cavity surface of the electroformed part must be sprayed with white oil before and after processing (to remove the white oil, please use mold cleaner or clean cotton dipped in Tina Apply water on it, and then use dry cotton to absorb it (never blow it directly with an air gun), and put tape on it. This will provide double protection to prevent the casting cavity surface from being scratched.
3. Because the electroformed surface finish of the Bicycle Reflector reflex mould is very demanding, and the surface texture is very fine and will be damaged at the touch of a touch, so do not allow hard objects to come into contact with it, and do not touch it with your fingers.
4. All Bicycle Reflector reflex mould electroforming molds must be based on the electrocasting part when closing the mold. It is forbidden to perform secondary processing such as milling or grinding on the molded electroforming part to cause insertion or breakage on the mold. When closing the mold, It is absolutely indispensable to detect the data of the front and rear mold cores.
5. The depth of the exhaust groove on the Bicycle Wheel reflector mold electroforming part is generally 0.01~0.015mm and the width is 3~4mm. It must be processed with a precision grinder or precision EDM.
6. Bicycle Wheel reflector mold Electroforming molds must prevent the product from sticking to the mold, and attention must be paid to all aspects of design, processing and polishing.
